Contact CSKey features
Through the secondary sealing, the sealing edge is smooth, with good air tightness, high dimensional accuracy, high efficiency and good consistency;
Internal pressure gauge, which can observe and accurately control the size of the sealing pressure;
Using hydraulic drive, large pressure up to 8T, battery seal without vibration, no leakage;
Special designed hydraulic structure, labor-saving operation;
Precision mold design to ensure the accurate and reliable sealing molding, firm steel structure design, stable and safe use;
Small size, easy to operate, can be placed in the glove box for operation;
Beautiful appearance, simple maintenance, has a small size, convenient operation, accurate molding and other advantages.
Technical parameters
Seal mold: standard 18650 series packaging mold, optional other specifications.
The operating strength of the joystick is less than 6kg.
The pressure gauge reading for the normal cylindrical battery packaging pressure is around from 80 ~100 kg/cm2, the machine has been adjusted before the factory, such as in special circumstances greater pressure is needed(maximum pressure is 200kg/cm2, about 8 tons of pressure) to consult the manufacturer before adjusting.
Mold material imported from Japan.
Structural material: High-strength chromium steel, The surface is treated with environmentally friendly electroplating and spraying, and will never rust.
Dimensions: 235×190×360mm (L×W×H).
Weight: 35kg.
